Quick RRC+ Receiver with P02+ Transmitter

The RRC radio control receiver is a device which combined with an RRC radio transmitter is suitable for controlling the operation of devices or accessories installed on recreational crafts.

The advantages offered by the RRC radio receiver are:
• Full supply range (from 10.5 to 31 Vdc).
• Microcontroller-operated functions.
• FSK modulation and carrier frequency 869.8 Mhz.
• Operating temperatures from -15°C to +70°C.
• Indication of the system operating status, errors and problems by means of LED and seven-segment display.
• Protection against polarity inversion.
• Protection against the discharge of the battery.
• 50 transmitters can be stored.
• Translation mode to activate more receivers, installed in different spots, by means of one transmitter.
• Programmable digital filter.
• Two functions can be activated at the same time.
• Possible connection to an external antenna.

Quick RRC P02+ 869MHz Anchor pocket radio transmitter 2-channel
The RCC pocket radio transmitter is a device which combined with a RRC radio receiver is used to control operation of devices or accessories installed on recreational crafts.

• Microcontroller-operated functions.
• Operating temperatures from -15°C to +60°C.
• FSK modulation and carrier frequency 869.8 MHz.
• Transmission feedback and low battery indication by means of LED.
• Possibility to control more receivers with one transmitter.
• Two functions can be activated at the same time.
• Floating.

When any of the transmitter keys is pressed, the green transmission LED flashes quickly and signals that transmission has taken place. It is possible to press up to two keys at the same time, while pressing 3 or more keys simultaneously cancels transmission (transmission LED switched off).

Each key pressed corresponds to the activation of a relay on the receiver (see RRC radio receiver manual), which will stay active as long as the key isn’t released.
It is recommended to replace the battery within a short period of time if the transmission LED is red during operation. The residual autonomy time depends on the quality of the battery used.

The pocket transmitter is powered using a lithium CR2450 battery.

Technical data:
- Model: P02+;
- Number of keys: 2;
- Carrier frequency: 869.8 MHz;
- Absorption during transmission: 13 mA;
- Modulation: FSK;
- Power supply: CR2450 alkaline 3 V lithium battery;
- Working temperature: -15°C +60°C;
- Dimensions: 47x60x23 mm;
- Weight: 35 g;
- Compliant with directive: 2014/53/EU (RED).

In The Box
RRC radio control receiver
Pocket Radio Transmitter & Lanyard
Batteries
Protective Case
Conditions of Warranty
Installation and User Manual

MANUALS AND GUIDES
