Simrad R3016 Radar Control Unit


RRP: £3,949.99
(You save £230.00 )
Adding to cart… The item has been added

Product Overview


Simrad R3016 Radar Control Unit | 000-12188-001

simrad pro marine radar r3016 large front view

The Simrad R3016 Radar Control Unit is a 16” widescreen dedicated radar display that provides simple, low impact installation with no separate processor and embedded console design, this radar display also allows for NMEA 0183 and NMEA 2000 network connectivity. Features include highly advanced digital auto tuning system, latest generation anti-sea clutter STC, ease-to-use with 8 direct-access menu keys and superior target resolution with advanced beam sharpening technology (available with 4G and Halo). In addition, The display can be controlled remotely with the optional O2000 wired remote controller.

    • Dedicated Radar display
    • Display - 16” widescreen | 300 cd/m2 Brightness | 1366 x 768 Resolution | LED-backlit Colour TFT LCD
    • Simple, Low Impact Installation
    • Bracket or Flush Mount Options
    • Simple Operation with 8 direct-access Menu Keys
    • Highly Advanced Digital Auto Tuning System
    • Anti-Sea Clutter STC
    • Superior Target Resolution
    • Meets IEC 62552 (pending) for small craft RADAR requirements for Class A vessels (When paired with specified Simrad Radar)
    • Network - 4x NMEA0183 | 1x NMEA2000 | 1x Ethernet | 1x HDMI Video Repeater Output
    • Remotely Controlled by Optional O2000 Wired Controller
    • Waterproof Rating - IPX6
    • Dimensions - 455.5 mm / 17.93 in x 260.1 mm / 10.24 in x 61 mm / 2.40 in | W x H x D
    • Weight - 4 kg / 8.8 lb
    • Power - 12-24 V DC
    • Power Consumption - 20W



simrad r2009 r3016 stand alone radar quick user manual simrad r2009 r3016 stand alone radar quick reference


*If you have trouble opening the pdf file, please try installing Adobe Acrobat reader on your device.
