Lowrance ActiveImaging HD 3-in-1 FishReveal Transducer | 000-16060-001

Step up to the ultimate fishfinding clarity with new, high-definition Active Imaging HD 3-in-1 sonar. Get the clearest images of fish and structure from Lowrance CHIRP sonar, high-frequency (up to 1.2MHz).

ActiveImaging HD 3-in-1 (Medium/High) – SideScan Fish Reveal. Delivers the highest-definition views of CHIRP, SideScan, and DownScan Imaging in one transducer + SideScan Fish Reveal when connected to an S3100 sonar module.

• High definition (up to 1.2MHz) SideScan and DownScan Imaging deliver the clearest images of fish and structure
• Lowrance CHIRP with superb clarity and target separation
• FishReveal* with new SideScan view as well DownScan
• Supports Medium and High CHIRP (83/200kHz) and 455/700/1000/1200 KHz frequencies
• Smart transducer design boosts signal clarity
• Compatible directly with Lowrance HDS PRO or with a S3100 module with HDS LIVE, HDS Carbon and Elite FS.
*requires S3100 sonar module for Fish Reveal SideScan

Specifications:
Mounting Type Transducer: Bracket Mount
Weight Transducer: 2.67 lbs (1.21 kg)
Frequencies: CHIRP: High CHIRP Medium CHIRP Broadband: 83 kHz 200 kHz
Active Imaging HD: SideScan: Low CHIRP: 455 kHz (445 kHz - 495 kHz)
High CHIRP: 1075 kHz (1065 kHz - 1115 kHz)
DownScan: Low CHIRP: 700 kHz (690 kHz - 740 kHz)
High CHIRP: 1200 kHz (1190 kHz - 1240 kHz)
Max Depth 2D Sonar: Broadband/CHIRP: 200 kHz/High CHIRP - 500' (152.4m) 83 kHz/Medium CHIRP - 1000' (304.8m)
SideScan: High Frequency: 150' (45.72m) Low Frequency: 300' (91.44m)
DownScan: High Frequency: 150' (45.72m) Low Frequency: 300' (91.44m)
