Raymarine RVX1000 3D CHIRP Sonar Module

Raymarine

RRP: £1,645.00
£1,480.50
(You save £164.50 )
Raymarine RVX1000 3D CHIRP Sonar Module Front
SKU:
E70511
Adding to cart… The item has been added

Product Overview



Raymarine RVX1000 3D CHIRP Sonar Module | E70511

raymarine rvx1000 sonar module front transparent

The RVX1000 offers all of the sonar performance and features of Raymarine Axiom Pro in a remotely mounted black box sonar module. With Raymarine’s award winning RealVision 3D sonar technology, CHIRP Side and DownVision, plus a high powered 1kW dual channel CHIRP sonar, the RVX1000 is a versatile sonar solution for both inshore and offshore fishing. All-in-one sonar module with 5 channels for both inshore and offshore fishing. Easily identify structure and locate fish with the life-like clarity of RealVision 3D sonar. Sonar Scroll Back lets you rewind, pause and playback up to 10 minutes recorded sonar history to take a closer look at fish and structure, and easily plot waypoints. TruZoom™ magnification reveals extra target detail without loss of resolution. RealVision 3D™ sonar with GPS Track feature uses precision GPS to construct the most accurate 3D model of the underwater world, in real-time. Powerful 3D sonar upgrade solution for Raymarine eS and gS Series line of multifunction displays. The RVX1000’s dedicated quad core processor allows previous generation MFD’s to run multiple sonar channels simultaneously without any compromise in performance.

    • Sonar: RealVision 3D (CHIRP Side and DownVision, High Frequency CHIRP, 3D Sonar) + 1kW High Power CHIRP
    • Sonar Depth: High Frequency CHIRP = 900 feet | DownVision = 600 feet | SideVision = 300 feet Port and Starboard | 1kw = 5,000 feet
    • Network: 1x RVX Port = 25 pin RealVision connector | 1x 1kw Port = 11 pin 1kW connector | 1x Power connection | 1x Raynet connection
    • Nominal Supply Voltage: 12 V and 24 V DC
    • Operating Voltage Range: 10.8 V to 31.2 V DC
    • Power Consumption: 10.4 W (Maximum)
    • Current: 2.4 A Peak; 1.2 A RMS
    • Waterproof Rating: IPX6/IPX7
    • Operating Temperature: -25 C (-13 F) to +55 C (+131 F)
    • Storage Temperature: -30 C (-22 F) to +70 C (+158 F)
    • Compatible Display: Axiom / Axiom Pro | eS Series / gS Series
